| Genset Technical Specification |
| Genset Rating ( kVA ) |
25 |
| Power Rating ( kW ) |
20 |
| Current ( Amps ) |
108.7/34.8 |
| Phase |
1/3 |
| Power Factor |
0.8 |
| Canopy Dimension (LxWxH ) |
1950X950X1683 |
| Cooper Engine Specifications |
Cooper |
| Engine Model |
2A5D1A31.4CW |
| Rated Power in kW (hp) |
31.4(42.7) |
| Aspiration |
TCIC |
| Cooling Systems |
Liquid Cooled |
| Starting Systems |
15 Volt Electrical |
| No of Cylinders |
2 |
| Bore X Stroke ( mm ) |
87X100 |
| Engine Speed ( rpm ) |
3000 |
| Fuel Tank Capacity ( Liters ) |
75 |
| Lube Oil Specifications |
15W40CI4+ |
| Genset Dry Weight ( kgs) |
750 |
| Alternator Specifications |
|
| Type |
Brushless |
| Voltage |
230/415 |
| Speed / Frequency |
3000RPM/50HZ |
| Voltage Regulation |
+/-1% |
| Enclosure |
IP23 |
| Class of Insulation |
Class H |
| Generator Model Also Available in 1800 RPM / 60 Hz |
